Fiber Optics in the LAN and Data Center

Title:

Description:

We will cover OM1-OM4 multimode cables, and introduce the new OM5 cable for 100-400G.  Understand cable connectors used in LAN and today's Data Centers.   Build a modern transceiver, and learn about SerDez and the critical ASIC chips that drive higher speeds in the Data Center.

A critical view of the cost/benefits of transceiver options.   Look at the MPO/MTP connectors and how they transform fiber density.

If you would like to support the channel, Join our channel membership, it’s $2.99/month (less than a Starbucks coffee); see the “Join” button on our channel homepage.  https://www.youtube.com/channel/UCCAXBGYIJnScl0IFKXOIlsQ/join
OR
Subscribe to the channel as it helps our channel perform better on YouTube’s algorithm.

0:00 Introduction
2:26 LAN vs Data Center
3:13 Core size is important
3:41 Fiber cores....
4:09 Fiber cable: legacy
6:10 OM1 -OM4 cable standards
8:27 1-U breakout trays using MPO connector and cables
8:44 Dense Wave Division Multiplexing
8:58 CWDM bandwidth grows each year
9:40 newest fiber cable
10:04 Single-mode, 8-10-micron cable
10:17 OS1 and OS2 fiber optic cables
10:48 Fiber jacket colors
11:07 Non-standard color cables
11:17 Connector color code
11:24 Connector Body
11:35 Outer Jacket is important
11:48 Plenum space
12:53 Fiber cable jacket types
15:10 SC connector
16:47 MU Connector
17:15 MT-RJ connector
17:44 E2000 Connector
19:08 MPO/MTP straight-through cable
20:22 Fiber connector tips: ferrule
22:10 Optic problems
23:21 Picking the right fiber connector: PC, UPC or APC
24:05 Transceivers: the key to fiber optics
24:17 Transceiver Basics
24:36 Optic Transceivers and Fiber cables
26:20 A Serializer/Deserializer
27:01 Let's build the newest fiber transceiver: 100GBASE-SR4 QSFP28
27:27 TRANSMITTER OPTICAL
30:14 High bandwidth transceivers can "breakout" to many lower bandwidth transceivers
30:46 Optical Internetworking Forum
